TD Series /

TD6

The TD6 is a truly unique musical performer and intended for those who wish to come as close to the “real thing” as possible.

Find A Dealer
No items found.

arrows & pagination

Style Guide

Raidho TD6

The TD6 is the one that does it all.

Even though it looks very similar to the highly acclaimed D5 and D5.1. The TD6 is a completely new development, only parts of the visual appearance look close to the previous models.

‍

The modular build cabinet system is capable of delivering unprecedented low-frequency clarity and speed, natural tonality, and texture. It’s the foundation that allows the TD6 to bring performers and their performance to life; the energy from a bowed double bass or the crisp snap of a snare drum; the searing edge of a scintillating guitar solo or the whisper of the most intimate vocal; that let’s you feel the music as well as hear it. The TD6 is the one that does it all.

‍

TD6 version of the tweeter, the foil itself has been upgraded to be able to handle even more power and higher dynamics.

‍

It is a large and highly sophisticated loudspeaker, but at Raidho we prefer to think of our flagship as a musical time machine. Choose a concert – any concert – and the TD6 can take you there.

‍

The TD6 seduces the listener. You are transported to another time and place and forget everything else around you. This is truly a world class reference speaker.

Image of the back from a Raidho Acoustics Driver

Raidho Series X
‍Drive Unit

This drive unit is not only highly advanced and built in-house in Denmark, but is also a piece of art.

The result is that the speakers disappear even more from the equation, drawing a soundscape without audible distortion and with a pitch-black background that made the instruments stand out and create holographic sound stage.

Read More
No items found.
No items found.
No items found.
No items found.
No items found.
No items found.
No items found.
No items found.
No items found.
No items found.
No items found.
Image of a Raidho Driver from the back

Raidho Series TD
‍Drive Unit

This is truly a unique and revolutionary drive unit! 100% developed and build inhouse by Raidho. The goals was simple: no coloration and outstanding dynamic capabilities.
‍
The motor comprises of a very strong magnet (N52 Neodymium) with an unseen even magnet field, coupled with an underhung titanium voice coil. This arrangement gives the drive unit the most powerful underhung magnet system in the world. The benetfit from an underhung voicie coil over the traditional overhung, is that it is much more linear and better dynamic capabilities. The result is perfect transient response with no measurable distortion.

Read More
Image of a Raidho Tweeter

The Legendary Raidho Ribbon Tweeter

Our proprietary, trademark ribbon tweeter is a unique design. It is completely designed and build by hand in-house in Denmark. To be exact, it is a Planar Magnetic Tweeter due to the tracks in the foil. The foil is 11 micron thick, which means it is 50 times less mass in comparison to a conventional dome tweeter. This is because there is no voice coil and the extreme low weight of the foil (20 milligram). The result is virtually no resonances or distortion, and the breakup point is at an incredible 82 KHz! What you hear is amazing clear and natural sound. All the detail in the world, but no fatigue, no distortion, and no coloration!

Read More

Our Awards

No items found.
No items found.

Photo Gallery

What the press is saying about the

Raidho TD6

SOUNDSTAGE GLOBAL AT THE HIGH END SHOW 2022:

“The soundstage was immense and enveloping. This system offered staggering levels of detail, slam, power, and bandwidth, while dynamic range was off the scale. Once heard, never forgotten.”

Quote

ENJOY THE MUSIC AT THE HIGH END SHOW 2022:

“Even the crossover is extreme with the elements connected using Nordost cable behind the board, not something I’ve ever encountered before. The sonic result was suitably room-filling and the bass was on the next level even by the standards of high-end luxury audio.”

Quote

HIFI PIG AT THE HIGH END SHOW 2022:

“A truly stunning speaker, they did not disappoint during listening. The stand out track was a live version of Kraftwerk’s ‘Radioactivity’. Electronic music showed of the speed of the drives and the sound even seemed to come from around and behind you when sat in the sweet spot in the GamuT chair.”

Quote

Technical Information

Dimensions

Topology
3 way
Bass Loading
Vented design. Six ports in the rear
Drivers

1 x TD6 Ribbon Tweeter

2 x 5” Tantalum Diamond mid-range drivers

6 x 8” Tantalum Diamond bass drivers

Crossover Point
350 Hz and 3 kHz 2. order
Frequency Range
25 Hz – 50 KHz +/-3 dB
Sensitivity
87 dB 2,83 V/m
Nominal Impedance
8 Ohm
Power Requirement
>100 W
Finish
Piano Black, Walnut burl veneer or any colour to order
Dimensions WxHxD, mm
590x2100x810 including feet
Enclosure WxD, mm
250 x 680
Weight, kg
130
Amplification
Width external, cm
A & B
70,5
Width inside, cm
A & B
62,8
Depth, cm
A & B
49
Height external, cm
A 12,4
B 25,2
Height inside, cm
A 8,7
B 21,5
Maxload,kg
A & B
90
Weight A, kg
12,5
Weight B, kg
16
